Corona DS929HV Servo - 2.4kg (33.3ozin), 0.09 sec - 12.5g Digital High Voltage

$7.00
/
Shipping calculated at checkout.
  • In stock, ready to ship
  • Inventory on the way

A low price, high speed, high voltage servo

Corona presents the DS929HV, this budget metal gear, high voltage servo is quick, yet puts out up to a fair 2.4kg of torque.

Dimensions 22.5X11.5X24.6mm(0.88x0.45x0.96in)
Operating Voltage 6.0 ~ 7.4V
Operating Current 200mA / 240mA
Speed 0.10sec.60º/ 0.09sec.60º
Stall Torque 2.2kg.cm /2.4kg.cm
Dead Band ≤3uSec
Travel 40º/one side pulse traveling 400us
Position Sensor 2 wiper / Direct Drive Potentiometer
Ball Bearing MR85
Gear Train Metal
Wire Length 215mm
Operating Temperature Range -20℃～+60℃
Compatibility na
Special Features na
Weight 12.5g (.44oz)
